Automatic Drill Point Grinder - Cuoghi APE 60A & 80A

Capacity:
APE 60A drill diameter range.....................6 - 60 mm / .236" - 2.362"
APE 80A drill diameter range.....................10 - 82.5 mm / .393" - 3.248"

Point angles.............................................90° to 140°
Cutting angle with regard to the
dia. of the twist drill...................................3° div. 14°^---3° div. 16°
Number of cutting edges (left and right).......2-3-4
Tool Feed (roughing-finishing).....................REV/1'0,52-0,26
Motor Power on feeding.............................KW 0,05
Chuck rotation speed for drills with
2-3-4 cutting edges...................................REV/1'42-28-21
Motor Power on chuck rotation...................KW 0,36

Grinding wheel:
Dimensions..............................................178x50x76 mm
Rotation Speed.........................................REV/1'3100
Motor Power.............................................KW 1.1 - KW 2.2

Cooling pump:
Tank capacity...........................................30 liters / 7.9 gal.
Electrical motor power...............................KW 0,10

Standard accessories:
Precision chuck with 3 sets of jaws
Tool centering device for APE 60A MT3, MT4, MT5
Tool centering device for APE 80A MT3, MT4, MT5 and MT6
Grinding wheel 180x50x76 54 grit
Safety device on drill chuck
Low voltage control panel
Automatic feed of the drill
Equipment for grinding wheel dresser
Wheel dresser diamond ct. 1
Instruction manual

Optional accessories:
Extension for sharpening extra long twist drills
Halogen lamp HP 20 220V WS
Grinding wheel balancer
